High Strength Micro Powder Mill

High Strength Micro Powder Mill

Key Specifications

Feeding sizes: ≤15-≤25mm

Production capacity: 0.6-52 t/h

Applicable materials: Limestone, calcite, calcium carbonate, dolomite, barite, talc, gypsum, diabase, quartz, bentonite, etc.

Applications: Calcium carbonate crushing and processing, gypsum powder processing, power plant desulfurization, non-metallic mineral milling, and pulverized coal preparation.

Email us: vip@zdzg.com
Get Quotation Inquiry Online

Product Introduction

The High-strength Grinding Mill produced by Henan Zhongde Company is widely used for crushing and high-fine powder processing more than 280 kinds of materials like barite, limestone, ceramics, slag, other non-flammable and explosive mines, metallurgy, chemicals, building materials, etc whose Mohs hardness is not more than 9.3, and humidity is below 6%. The finished particle size adjust in the range of 80-425 mesh (the smallest is 1000 mesh).

  Through the special device added in the machine, it can produce 30-80 mesh of coarse powder. High-strength Mill is also called High-efficiency Mill, Hanging- roller mill or Ore Grinding Equipment.

Advantages of High Strength Grinding Mill:

1. Three-dimensional structure, small occupied area, strong quality of complete sets. It is an independent production system from the block material to the finished powder.

2. Uniform-fineness finished powder, 99% screening rate, which is difficult for other milling equipments to possess.

3. The gearing adopts a closed gearbox and pulley which transmit smoothly, and operates reliably .

4. All important parts adopt high-quality steel, and all wear-resistant parts adopt high-performance wear-resistant materials. The whole machine operates reliably with high –performance wear-resisting property.

5. The electrical system adopts centralized control, the milling workshop can basically achieve unmanned operation, and it is easy to maintain.

Technical Data

     Parameter
Model		 Feeding
size（mm）		 Size of finished
product（mm）
High-strength97 <25 0.173-0.033
High-strength93 <25 0.173-0.033
High-strength92 <25 0.173-0.033
High-strength87 <25 0.173-0.033
High-strength76 <20 0.173-0.033
High-strength66 <15 0.173-0.033
High-strength62 <15 0.173-0.033
Raymond mill4119 ≤25 0.173-0.044
Raymond mill4525 ≤30 0.173-0.044
