Production capacity: 50–650 t/h
Feeding size: 350-800 mm
Output size: 65–200 mm
Applications: urban construction waste, water conservancy and hydropower, mineral processing, ceramics,etc.
The emergence of construction waste mobile crusher eliminates the need for transportation of materials, which can save a large amount of transportation costs. For some areas where the crushing site is small and the operating environment is not convenient, the mobile building crusher has a very good crushing effect. The cost of a whole set of purchase cost is much cheaper than the purchase price of a single device.
.jpg)
When users purchase the equipment, the company will help to select machines based on the user's local stone raw material type and the production and finished product requirements of the specific circumstances of the equipment to select the configuration. The specific selection of several broken sieve system needs to be selected according to the user's processing needs.

1. It can be moved, and it is not necessary to carry out the transportation of materials. It can be directly driven to the site playing a very important role in the treatment and reuse of urban construction waste.
2. High degree of integration, the raw materials are processed to the required finished products, and the overall production efficiency is high and the cost of consumption is low.
.jpg)
3. The technology of mobile building waste crusher is more mature, the procurement cost is lower and lower, the progress of science and technology makes the equipment more efficient and cost saving.
4. Low overall transport costs, the cost of "turning waste into treasure" is lower, and the equipment is directly driven to the construction waste site for processing.
5. The economic and social benefits of mobile construction waste crushers are incalculable and will be strongly supported by the state.

Model HX938HD86 and HX1149HD98
| Model | HX938HD86 | HX1149HD98 |
| Transportation lenght(mm) | 12600 | 13500 |
| Transportation Width(mm) | 2600 | 2700 |
| Transportation Height(mm) | 3870 | 4200 |
| Maximum Lenght(mm) | 12500 | 14000 |
| Maximum Width(mm) | 4100 | 4500 |
| Maximum Height(mm) | 4100 | 4900 |
| Weight(t) | 39 | 57 |
| tIRE Configuration | Dualaxial | Dualaxial |
| Jaw Crusher | HD86 | HD98 |
| Maximum Feeding Size(mm) | 500 | 550 |
| Discharge opening range | 50-150 | 75-175 |
| Capacity(t/h) | 85-275 | 110-350 |
| Vibrating Feeder | ZSW380×95 | ZSW420×110 |
| Main Belt Conveyor | B800×8.5m | B1000×9.5m |
| Side-opening Belt conveyor(optional) | B500×3m | B650×3.5m |
| Gensrt(optional) | 200KW | 250KW |
| Iron separator(optional) | RCYD(C)-8 | RCYD(C)-10 |
Model HX1349HD110 and HX1349HD125
| Model | HX1349HD110 | HX1349HD125 |
| Transportation lenght(mm) | 14500 | 15200 |
| Transportation Width(mm) | 2800 | 2900 |
| Transportation Height(mm) | 4450 | 4500 |
| Maximum Lenght(mm) | 16100 | 16700 |
| Maximum Width(mm) | 5100 | 5100 |
| Maximum Height(mm) | 5000 | 5300 |
| Weight(t) | 55 | 65 |
| Tire Configuration | Dualaxial | Dualaxial |
| Jaw Crusher | HD110 | HD125 |
| Maximum Feeding Size(mm) | 660 | 800 |
| Discharge opening range | 100-200 | 125-225 |
| Capacity(t/h) | 215-510 | 280-650 |
| Vibrating Feeder | ZSW490×130 | ZSW490×130 |
| Main Belt Conveyor | B1000×11m | B1200×11m |
| Side-opening Belt conveyor(optional) | B650×4m | B650×4m |
| Gensrt(optional) | 270KW | 400KW |
| Iron separator(optional) | RCYD(C)-10 | RCYD(C)-12 |
