Mobile Cone Crusher

Mobile Cone Crusher

Key Specifications

Production Capacity: 27-445t/h

Feeding Size: 175-241mm

Weight: 34.5-49.5 tm

Applicable materials: river pebbles, rocks, limestone, granite, basalt, diabase, andesite, ore tailings.

Email us: vip@zdzg.com
Get Quotation Inquiry Online

Product Introduction

Mobile cone crusher is one of the most common construction waste mobile crushing station. It is not only used to deal with construction waste, but also for many types of ores. The emergence of the mobile cone crushing plant in accordance with the people's fast rhythm, high efficiency production requirements. It saves material transportation, low investment cost.

Performance characteristics

1. Integration of cone crusher and supporting crusher and auxiliary equipment to enhance the system of production.
2. Integrated vehicle installation can be opened to the site to process and save the transportation of materials.
3. The installation support of the vehicle, the site is more convenient and efficient.
4. The motor and fuel tank are integrated, and the coordination between each configuration is stronger.

Working Principle

The material processed by mobile cone crusher can be screened after being crushed or before being crushed. There are several stages of crushing and screening systems like coarse crushing, fine crushing and intermediate crushing for large piece of stone.
According to the actual needs, users will select specific equipment. The screening process is to control the stone specifications, qualified crushed stone enter the processing of next working procedure. Mobile cone crushing plant is composed of a cone crusher and other equipment. It is popular in the marketing of Mining and crushing industry.

Technical Data

Model HX3S185GYS300 HX3S216GYS400 HX3S216HP300
Transportation length(mm) 14500 15000 16000
Transportation Width(mm) 3000 3000 4550
Transportation Height(mm) 4400 4500 4600
Maximum Length(mm) 17000 16000 17000
Maximum Width(mm) 3400 3900 6900
Maximum Height(mm) 5800 6500 4700
Weight(t) 34.5 49.5 41
Tire Configuration Dualaxial Triaxial Triaxial
Cone crusher GYS300 GYS400 HP300
Discharging belt Conveyor B650×15M×2 B800×15M×2 B800×15M×2
Return belt conveyor B650×14M B800×14M B800×16M
CONveyor Belt For Final Products B500×15M B800×6M B650×15M×2
Under Virbrating Screen B800×7M B800×8M B800×9M
Vibrating Screen 3YK1854 3YK2160 3YK2160
